TL-WR720N

  • 150Mbps wireless transmission rate ideal for Internet surfing, e-mail and online chat
  • Up to 4 SSIDs support multiple wireless networks with different SSIDs and passwords
  • Easy wireless security encryption at a push of WPS button
  • IP based bandwidth control allows administrators to determine how much bandwidth is allotted to each PC
Category:

Description

150Mbps Wireless N Router

  • 150Mbps wireless transmission rate ideal for Internet surfing, e-mail and online chat
  • Up to 4 SSIDs support multiple wireless networks with different SSIDs and passwords
  • Easy wireless security encryption at a push of WPS button
  • IP based bandwidth control allows administrators to determine how much bandwidth is allotted to each PC

Note: TL-WR720N V2 contains one external fixed antenna, while TL-WR720 V1 contains one internal antenna.

For More Info Please Visit www.tp-link.com



HARDWARE FEATURES
Interface 2 10/100Mbps LAN Ports
1 10/100Mbps WAN Port
Button WPS/Reset
Dimensions (W X D X H) 6.2 x 4.8 x 1.3 in.(158 x 122 x 32 mm)
Antenna 5dBi Fixed Omni Directional
External Power Supply 5VDC / 0.6A
WIRELESS FEATURES
Wireless Standards IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Frequency 2.4-2.4835GHz
Signal Rate Up to 150Mbps
Reception Sensitivity 130M: -68dBm@10% PER
108M: -68dBm@10% PER
54M: -68dBm@10% PER
11M: -85dBm@8% PER
6M: -88dBm@10% PER
1M: -90dBm@8% PER
Transmit Power CE:
<20dBm(2.4GHz)
FCC:
<30dBm
Wireless Functions Enable/Disable Wireless Radio, WDS Bridge, WMM, Wireless Statistics
Wireless Security 64/128/152-bit WEP / WPA / WPA2,WPA-PSK / WPA2-PSK
SOFTWARE FEATURES
Quality of Service WMM, Bandwidth Control
WAN Type Dynamic IP/Static IP/PPPoE/ PPTP/L2TP/BigPond
Management Access Control
Local Management
Remote Management
DHCP Server, Client, DHCP Client List, Address Reservation
Port Forwarding Virtual Server, Port Triggering, UPnP, DMZ
Dynamic DNS DynDns, Comexe, NO-IP
VPN Pass-Through PPTP, L2TP, IPSec (ESP Head)
Access Control Parental Control, Local Management Control, Host List, Access Schedule, Rule Management
Firewall Security DoS, SPI Firewall
IP Address Filter/MAC Address Filter/Domain Filter
IP and MAC Address Binding
OTHERS
Certification CE, FCC, RoHS
Package Contents TL-WR720N
Power Supply Unit
Resource CD
RJ-45 Ethernet Cable
Quick Installation Guide
System Requirements Microsoft® Windows® 2000, XP, Vista™ or Windows 7, Windows8/ 8.1/10
MAC® OS, NetWare®, UNIX® or Linux
Environment Operating Temperature: 0℃~40℃ (32℉~104℉)
Storage Temperature: -40℃~70℃ (-40℉~158℉)
Operating Humidity: 10%~90% non-condensing
Storage Humidity: 5%~95% non-condensing
