TD-8817

  • Provide Internet access via ADSL Service and create a wired sharing network, all with one product
  • Works with the latest ADSL standards: up to 24Mbps downstream superior performance
  • Built-in firewall protects against Internet attacks
  • Various QoS policies enable various application, meeting people’s different needs
Category:

Description

ADSL2+ Ethernet/USB Modem Router

  • Provide Internet access via ADSL Service and create a wired sharing network, all with one product
  • Works with the latest ADSL standards: up to 24Mbps downstream superior performance
  • Built-in firewall protects against Internet attacks
  • Various QoS policies enable various application, meeting people’s different needs
  • IPv6 supported, meeting the demands for the next generation Internet
  • 6KV Lightning Protection helps your device avoid the damage of tough thunderstorms

For More Info Please Visit www.tp-link.com

HARDWARE FEATURES
Interface 1 10/100Mbps RJ45 Port
1 RJ11 Port
1 USB Port
Button 1 Power On/Off Switch
External Power Supply 5VDC/1A
IEEE Standards IEEE 802.3, 802.3u
ADSL Standards Full-rate ANSI T1.413 Issue 2, ITU-T G.992.1(G.DMT), ITU-T G.992.2(G.Lite)
ITU-T G.994.1 (G.hs), ITU-T G.995.1 , ITU-T G.996.1, ITU-T G.997.1, ITU-T K.2.1
ADSL2 Standards ITU-T G.992.3 (G.dmt.bis), ITU-T G.992.4 (G.lite.bis)
ADSL2+ Standards ITU-T G.992.5
Dimensions ( W x D x H ) 5.5*3.6*1.1 in.(140*92*29mm)
SOFTWARE FEATURES
Quality of Service QoS Remarking based on IPP/ToS, DSCP and 802.1p
Security NAT Firewall, MAC /IP /URL Filtering
IPv6 IPv6 and IPv4 dual stack
Supported IPv6 Tunnels: DS-Lite, 6RD, 6 to 4
Supported IPv6 Connection Type: PPPoEv6, DHCPv6, Static IPv6
Management Web Based Configuration(HTTP), Remote management, Telnet management, SNMP v1/2c, Web Based Firmware Upgrade, Diagnostic Tools
Port Forwarding Virtual server, DMZ, ACL(Access Control List)
VPN Pass-Through PPTP, L2TP, IPSec Pass-through
ATM/PPP Protocols ATM Forum UNI3.1/4.0,
PPP over ATM (RFC 2364),
PPP over Ethernet (RFC2516),
IPoA (RFC1577/2225),
PVC – Up to 8 PVCs,
Advanced Features Traffic Shaping(ATM QoS) UBR, CBR, VBR-rt, VBR-nrt;
Dynamic Host Configuration Protocol (DHCP), DHCP relay;
Network Address Translation (NAT);
Static Routing, RIP v1/v2 (optional);
DNS Relay, DDNS
IGMP Multicast, UPnP
OTHERS
Certification CE, FCC, RoHS
Package Contents TD-8817
External Splitter
RJ-11 Telephone Cable
RJ-45 Ethernet Cable
USB Cable
Quick Installation Guide
Resource CD
Power Adapter
System Requirements Microsoft® Windows® 98SE, NT, 2000, XP, Vista™, Windows 7, Windows 8 or MAC® OS, NetWare®, UNIX® or Linux.
Environment Operating Temperature: 0℃~40℃ (32℉~104℉)
Storage Temperature: -40℃~70℃ (-40℉~158℉)
Operating Humidity: 10%~90% non-condensing
Storage Humidity: 5%~90% non-condensing
